The vacuuming nozzle of a wood grain effect sublimation machine is a component designed to assist in the sublimation transfer process, specifically for creating wood grain patterns on surfaces such as aluminum profiles or other substrates.

Vacuuming nozzle of wood grain effect sublimation machine is mainly used for aluminum profile surface treatment equipment, which is single bag vacuum wood grain heat transfer equipment.

The water circulation vacuum pump is used to guide the vacuum suction nozzle through the bracket to guide the aluminum profiles, so that the surface of the aluminum profile is wrapped with wood grain paper or film with different patterns, and then put into the high-temperature resistance cover bag.

In the vacuum nozzle slot, lock the fixed sleeve, open the high-temperature ball valve, extract the air in the high-temperature resistance cover bag, and make the wood grain paper or film closely contact the surface of aluminum profile.

The reverse blower blows up the high-temperature resistance cover bag, which is convenient for removing the wood grain paper, and the pattern on the surface of aluminum profile is clear, realizing the real wood grain effect.

The vacuum nozzle in a wood grain effect sublimation machine serves a crucial function in the sublimation process, particularly for transferring wood grain patterns onto substrates such as aluminum sheets or other materials

Features:

Vacuum System: The vacuum nozzle is equipped with a vacuum system that creates suction to hold the substrate firmly in place during the sublimation process.

This ensures that the substrate remains flat and stable, preventing any movement that could result in distorted or uneven transfer of the wood grain pattern.

Adjustable: The vacuum nozzle typically comes with adjustable settings to accommodate different sizes and types of substrates.

This versatility allows for precise positioning and alignment of the substrate to ensure accurate pattern transfer.

Durable Construction: The vacuum nozzle is usually constructed from durable materials such as stainless steel or aluminum to withstand the rigors of the sublimation process and maintain consistent performance over time.

Advantages:

Precise Registration: The vacuum nozzle helps to maintain precise registration between the wood grain pattern and the substrate, resulting in high-quality, accurately aligned transfers.

Eliminates Wrinkles and Distortions: By securely holding the substrate in place, the vacuum nozzle prevents wrinkles, bubbles, or other distortions from occurring during the sublimation process.

This ensures a smooth and uniform transfer of the wood grain pattern onto the substrate.

Increased Efficiency: The use of a vacuum nozzle streamlines the sublimation process by reducing the need for manual adjustments or interventions.

This improves efficiency and productivity, allowing for higher throughput and faster production times.

Function: The primary function of the vacuum nozzle in a wood grain effect sublimation machine is to securely hold the substrate in place during the sublimation process.

This is achieved through the suction generated by the vacuum system, which creates a tight seal between the substrate and the vacuum table or bed of the machine.

During operation, the substrate is placed on the vacuum table, and the vacuum nozzle is positioned over the substrate to create a seal.

The vacuum system is then activated, generating suction that holds the substrate firmly in place.

This ensures that the substrate remains flat and stable throughout the sublimation process, allowing for accurate and consistent transfer of the wood grain pattern onto the surface.

Overall, the vacuum nozzle plays a critical role in achieving high-quality wood grain effect sublimation prints by ensuring precise registration, eliminating distortions, and increasing efficiency in the production process.

Basic Principles of Equipment

1. From the principle of thermal sublimation transfer, each thermal transfer machine is a heating element with a different shape.

The temperature of the heating element is controlled within a range by an additional temperature controller.

At the same time, in order to conveniently control the sublimation transfer time, a time controller is added to remind the user when the set time is reached.

2. In terms of circuit principle, the thermal transfer device is a temperature controller and a time controller that jointly control an electric heating device.

The temperature and time can be set in advance.

The temperature of the electric heating device is stable at the set value, and the time will also be when the set value is reached, the power is automatically disconnected.

Of course, this heating body is made into a shape of a cylinder, a square flat surface, a round surface, etc according to different products for transferring different products.

For many years, our company has been market-oriented and has continuously developed new aluminum profile vacuum wood grain effect sublimation machine to meet the changing market and the needs of customers.

Our company believes that without quality, there will be no tomorrow for the enterprise.

We win the trust of customers with high quality, affordable price, short lead time and satisfied after-sales service.
